Engenius SA-2216 2×2 MIMO 2.4 GHz, 16 dBi Sector Antenna

Liên hệ

Gọi mua, hỗ trợ tư vấn 088 843 77 33

Trợ giúp tư vấn bán hàng

  • Hotline 088 843 77 33
  • Thời gian làm việc:

    Thứ 2 - Thứ 6: 08h - 17h

    Thứ 7: 08h - 12h

Hỗ trợ bán hàng:

Hỗ trợ kỹ thuật:

Hỗ trợ bảo hành:

Thông tin bổ sung
Operating Frequency

2.3 ~ 2.7 GHz

Radio Chains/Spatial Streams

2×2 MIMO

Gain

16dBi

Polarization

Dual

Vertical Beam Width

9-Degrees

Horizontal Beam Width

120-Degrees (6dB)

Max. VSWR

2:01

Cross-Pol Isolation

25dB

Impedance

50 ohms

Antenna Port / Type

2 / N-Type Plug Female

Access Point Mount Bracket

EnGenius APs – ENS202EXT (RP-SMA Connectors)

N-Type Connectors

EnGenius and most other outdoor APs with external antenna conectors

Temperature Range

Operating: -4°F ~ 158°F (-20°C ~ 70°C) Storage: -30°F ~ 80°F (-22°C ~ 176°C)

Humidity (non-condensing)

Operating: 90% or less Storage: 95% or less

Wind Survivability

125 MPH

Device

Weight: 11 lbs. (5 kg) Height: 29.13” (740 mm) Width: 5.9” (150 mm) Depth: 2.6” (66 mm)

Packaging

Weight: 9 lbs. (4 kg) Height: 39.9” (101.5 cm) Width: 5.9” (150 mm) Depth: 8.2” (210 mm)

Package Contents

(1) Sector Antenna (2) U-Brackets (2) Pole Brackets (2) Pole Clamps (4) Serrated Flange Bolts (4) Serrated Flange Hex Nuts (3) Mount Bracket Bolts (1) Protective Shroud (1) Access Point Mounting Bracket Quick Installation Guide

Compatible EnGenius Access Points

2.4 GHz Plug-in Mounting System ENS202EXT (w/ RP-SMA connectors – cable not included) Dual-Band 2×2 N-Type Connectors ENH710EXT
